layui实现自带的table组件分页功能,异步加载,表格渲染,含条件查询。


一:引入layUI的相关资源

1
2
<link rel="stylesheet" href="${ctxPath}/vendor/layui/css/layui.css">
<script src="${ctxPath}/vender/layui/layui.js" charset="utf-8"></script>

二:html页面代码

搜索表单:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
<div class="layui-row">
<form class="layui-form layui-col-md12 we-search">
项目搜索:
<div class="layui-inline">
<input type="text" name="projectName" id="projectName" placeholder="项目名称" autocomplete="off" class="layui-input">
</div>
<div class="layui-input-inline">
<select name="businessOperatorId" id="businessOperatorId" lay-verify="" lay-search>
<option value="">业务员</option>
</select>
</div>
<div class="layui-input-inline">
<select name="mftRepresentativeId" id="mftRepresentativeId" lay-verify="" lay-search>
<option value="">厂家代表</option>
</select>
</div>
<div class="layui-input-inline">
<select name="channelId" id="channelId" lay-search>
<option value="">渠道</option>
</select>
</div>
<div class="layui-input-inline">
<select name="customerId" id="customerId" lay-search>
<option value="">客户</option>
</select>
</div>
<div class="layui-input-inline">
<select name="projectPhase" id="projectPhase" lay-search>
<option value="">项目阶段</option>
</select>
</div>
<div class="layui-input-inline">
<select name="goodsCondition" id="goodsCondition" lay-search>
<option value="">货物情况</option>
</select>
</div>
<div class="layui-input-inline">
<select name="implementCondition" id="implementCondition" lay-search>
<option value="">实施情况</option>
</select>
</div>
<div class="layui-input-inline">
<select name="payCondition" id="payCondition" lay-search>
<option value="">收款情况</option>
</select>
</div>

<div class="layui-inline">
<input class="layui-input" placeholder="开项时间" name="startTime" id="startTime">
</div>
<div class="layui-inline">
<input class="layui-input" placeholder="结项时间" name="endTime" id="endTime">
</div>
<button class="layui-btn" lay-submit="" lay-filter="sreach"><i class="layui-icon">&#xe615;</i></button>
</form>
</div>

【注】以上搜索表单中select具体下拉选项的数据为Ajax异步加载,代码就不贴了。

数据表格:

1
<table class="layui-hide" id="projectList" lay-filter="projectList"></table>

三:后台接收分页参数以及查询条件,获取并返回数据

主要注意下:
page: 前台分页插件传入的当前页数,
limit: 前台分页插件传入的每页个数,
projectInfo :接收前台传入的查询条件的实体
jsonResult :后台返回的相关数据的响应实体

1
2
3
4
5
6
7
@ResponseBody
@RequestMapping("/project/list")
public JsonResult list(@RequestParam("page") Integer page, @RequestParam("limit") Integer size, ProjectInfoEntity projectInfo){

JsonResult jsonResult = projectService.getProjectList(page,size,projectInfo);
return jsonResult;
}

后台响应类必须包含code与count字段,因为前台layui会自动获取

自定义后台数据响应实体 JsonResult

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
package com.bhy702.jfkj.common.util;

/**
* JSON结果响应
*
*/
@Data
public class JsonResult {

private static final String SUCCESS = "成功";
private static final String ERROR = "失败";

/**
* 响应状态code,因为前台layui默认0为响应成功,所以此处默认为0
*/
private Integer code = 0;

/**
* 数据总条数
*/
private Long count = 0L;

/**
* 返回是否成功
*/
private Boolean result = false;

/**
* 返回提示信息
*/
private String msg = "";

/**
* 返回数据信息
*/
private Object data;

private JsonResult() {
}

/**
* 成功的响应
*
* @return
*/
public static JsonResult success() {
return result(true, SUCCESS, null,null);
}

public static JsonResult success(String msg) {
return result(true, msg, null,null);
}

public static JsonResult success(Object data) {
return result(true, SUCCESS, data,null);
}
public static JsonResult success(Object data,Long count) {
return result(true, SUCCESS, data,count);
}


public static JsonResult success(String msg, Object data) {
return result(true, msg, data,null);
}

public static JsonResult success(String msg, Object data,Long count) {
return result(true, msg, data,count);
}

/**
* 失败的响应
*
* @return
*/
public static JsonResult error() {
return result(false, ERROR, null,null);
}

public static JsonResult error(String msg) {
return result(false, msg, null,null);
}

public static JsonResult error(Object data) {
return result(false, ERROR, data,null);
}

public static JsonResult error(Object data,Long count) {
return result(false, ERROR, data,count);
}

public static JsonResult error(String msg, Object data) {
return result(false, msg, data,null);
}

public static JsonResult error(String msg, Object data,Long count) {
return result(false, msg, data,count);
}

public static JsonResult result(Boolean result, String msg, Object data,Long count) {
JsonResult jsonResult = new JsonResult();
jsonResult.setResult(result);
jsonResult.setMsg(msg);
jsonResult.setData(data);
jsonResult.setCount(count);
return jsonResult;
}
}

四:渲染table表格数据

主要注意下:
elem: ‘#projectList’: projectList为表格id,
page: true: 设置表格分页,
url: ‘/project/list’ :数据请求url
fixed: true:固定列
done : function(res, curr, count){…}:数据加载成功后的回调函数

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
var tableIns = table.render({
elem: '#projectList',
cellMinWidth: 150,
url: '/project/list',
cols: [
[{
// type: 'checkbox',fixed: 'left'
checkbox: true, fixed: true
}, {
field: 'id',title: 'ID',align:'center',width:50,fixed: true
}, {
field: 'name',title: '项目名称',align:'center',fixed: true
}, {
field: 'businessOperatorStr',title: '经办人',align:'center',fixed: true
}, {
field: 'mftRepresentativeStr',title: '厂家代表',align:'center',fixed: true
}, {
field: 'channelStr',title: '渠道',align:'center',fixed: true
}, {
field: 'customerStr',title: '客户',align:'center',fixed: true
}, {
field: 'projectPhaseStr',title: '项目阶段',align:'center',fixed: true
}, {
field: 'amount',title: '金额',align:'center'
}, {
field: 'businessSource',title: '商机来源',align:'center'
}, {
field: 'mainProduct',title: '主要产品',align:'center'
}, {
field: 'productLineStr',title: '产品线',align:'center'
}, {
field: 'goodsConditionStr',title: '货物情况',align:'center'
}, {
field: 'implementConditionStr',title: '实施情况',align:'center'
}, {
field: 'payAmount',title: '已付金额',align:'center'
}, {
field: 'payConditionStr',title: '收款情况',align:'center'
}, {
field: 'startTime',title: '开项时间',align:'center'
}, {
field: 'endTime',title: '结项时间',align:'center'
}, {
field: 'remark',title: '备注',align:'center'
}, {
field: 'operate',title: '操作',toolbar: '#operateTpl',fixed: 'right',unresize: true
}]
],
id: 'testReload',
// skin: 'row', //表格风格
even: true, //隔行背景
event: true,
page: true,
done : function(res, curr, count){
$('#totalProjectNumber').text("共有数据:"+count+" 条");
table_data=res.data;
layer.closeAll('loading');
// layer.close(layer.index); //它获取的始终是最新弹出的某个层,值是由layer内部动态递增计算的
// layer.close(index); //返回数据关闭loading
}
});

五:监听搜索表单的提交事件,并重新渲染table表格数据

主要注意下:
sreach: 为搜索按钮对应的事件过滤器,lay-filter=”sreach”,
where 中的数据对应搜索表单,为搜索的条件,后台使用这些条件进行筛选数据返回

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
form.on('submit(sreach)', function(data){

layer.load();
tableIns.reload({
url:"/project/list",
page: {
curr: 1 //重新从第 1 页开始
},
where:{
name:data.field.projectName,
businessOperatorId:data.field.businessOperatorId,
mftRepresentativeId:data.field.mftRepresentativeId,
channelId:data.field.channelId,
customerId:data.field.customerId,
projectPhase:data.field.projectPhase,
goodsCondition:data.field.goodsCondition,
implementCondition:data.field.implementCondition,
payCondition:data.field.payCondition,
startTime:data.field.startTime,
endTime:data.field.endTime
}
});

return false; //阻止表单跳转。如果需要表单跳转,去掉这段即可。
});

六:效果展示

在这里插入图片描述
